Using Virtual Desktops for Presentations


Today I was reading William Durkin‘s fine post on Presentation Mode in SSMS vNext when inspiration struck.

One of the things that really annoys me when presenting is the transition between slides and demos. Usually, I try to improve the process as much as possible by having the least minimum amount of windows open while presenting, so that I don’t land on the wrong window. Unfortunately, that is not always easy.

Another thing that I would like to be smoother is the transition itself. The ideal process should be:

  1. Leave the powerpoint slides open at full screen
  2. Switch immediately to the virtual machine with the demos
  3. Go back to the slides, to the exact point where I left

What I usually do is show the desktop with the WIN+D hotkey, then activate the Virtualbox window with my demos, but this shows my desktop for a moment and I don’t really like this extra transition.

I could also use ALT+Tab to switch to the Virtualbox window, but this would briefly show the list of running applications, which is not exactly what I want.

Turns out that Windows 10 has the perfect solution built-in: Virtual Desktops.

Here is the setup described:

  1. If you press WIN+Tab, you will see a “New desktop” button on the bottom right corner. Use it to create three desktops:
    1. desktop 3 for the slides
    2. desktop 2 for the demos
    3. desktop 1 for the rest
  2. Press WIN+Tab, find your virtual machine and move it to desktop 2. It is really easy: you just have right click the window you want to send to a different desktop and select which desktop to use.MoveToDesktop.png
  3. Open your presentation and start it by pressing F5. Again, hit WIN+Tab, find the fullscreen window of your PowerPoint presentation and move it to desktop 3.
  4. In order to transition from one desktop to another, you can use the hotkey CTRL+WIN+Arrow, as shown in this GIF:giphy

Here it is! Perfectly smooth, a nice transition animation and nothing but your slides and your demos shown to the attendees.

Upcoming Speaking Engagements


In the next few months I will be speaking at some awesome events around Europe.



SQLBits – April 5-8

sqlbitslogo

SQLBits is THE SQL Server event in Europe, with a very long tradition and a fantastic audience. I totally love SQLBits!
This time I will speak about “Benchmarking like a PRO“. In this session I will demonstrate how to capture a baseline with RML Utilities and how to replay it against a target machine to compare baseline and benchmarks. I will use a PowerShell script of my creation and I will walk you through the code and outcomes.



SQLNexus – May 1-3

sql_nexus_logo

SQLNexus is quickly gaining a reputation as a fantastic event, which is nothing but the truth.
My session is going to be again “Benchmarking like a PRO”, this time on a IMAX screen 🙂



SQLGrillen – June 2

t23_2xnq_400x400

“SQLGrillen: Databases, Bratwurst & Beer”. Not much to add 🙂
This time I will pose as Virgil and guide you through the SQL Server Hell in my “SQL Server Infernals” session.



SQLSaturday Dublin – June 17

sqlsat620_web

Dublin is a special place. I’ve been in Dublin as an attendee in 2014 and it’s a wonderful city, with one of the best SQL Saturdays I’ve ever been to.
I am honored to say that I will deliver my session “Responding to Extended Events in near real-time“.



That’s it for the moment. Enough to keep me busy for some time to come 🙂



Installing SQL Server 2016 Language Reference Help from disk


A couple of years ago I blogged about Installing the SQL Server 2014 Language Reference Help from disk.

With SQL Server 2016 things changed significantly: we have the new Help Viewer 2.2, which is shipped with the Management Studio setup kit.

However, despite all the changes in the way help works and is shipped, I am still unable to download and install help content from the web, so I resorted to using the same trick that I used for SQL Server 2014.

This time the URLs and the files to download are different:

    1. Point your browser to http://services.mtps.microsoft.com/ServiceAPI/catalogs/sql2016/en-us
    2. Download the Language Reference Files:

      If you’re a PowerShell person, these three lines will do:

Invoke-WebRequest -Uri "http://packages.mtps.microsoft.com/sql_2016_branding_en-us(1bd6e667-f159-ac3b-f0a5-964c04ca5a13).cab" `
	-OutFile "sql_2016_branding_en-us(1bd6e667-f159-ac3b-f0a5-964c04ca5a13).cab"
Invoke-WebRequest -Uri "http://packages.mtps.microsoft.com/v2sql_shared_language_reference_b4621_sql_130_en-us_1(83748a56-8810-751f-d453-00c5accc862d).cab" `
	-OutFile "v2sql_shared_language_reference_b4621_sql_130_en-us_1(83748a56-8810-751f-d453-00c5accc862d).cab"
Invoke-WebRequest -Uri "http://packages.mtps.microsoft.com/v2sql_shared_language_reference_b4621_sql_130_en-us_2(ccc38276-b744-93bd-9008-fe79b294ff41).cab" `
	-OutFile "v2sql_shared_language_reference_b4621_sql_130_en-us_2(ccc38276-b744-93bd-9008-fe79b294ff41).cab"
      1. Create a text file name HelpContentSetup.msha in the same folder as the .cab files and paste the following html:
<html xmlns="http://www.w3.org/1999/xhtml">
<head />
<body class="vendor-book">
    <div class="details">
        <span class="vendor">Microsoft</span>
        <span class="locale">en-us</span>
        <span class="product">SQL Server 2016</span>
        <span class="name">Microsoft SQL Server Language Reference</span>
    </div>
    <div class="package-list">
        <div class="package">
            <span class="name">SQL_2016_Branding_en-US</span>
            <span class="deployed">False</span>
            <a class="current-link" href="sql_2016_branding_en-us(1bd6e667-f159-ac3b-f0a5-964c04ca5a13).cab">sql_2016_branding_en-us(1bd6e667-f159-ac3b-f0a5-964c04ca5a13).cab</a>
        </div>
        <div class="package">
            <span class="name">v2SQL_Shared_Language_Reference_B4621_SQL_130_en-us_1</span>
            <span class="deployed">False</span>
            <a class="current-link" href="v2sql_shared_language_reference_b4621_sql_130_en-us_1(83748a56-8810-751f-d453-00c5accc862d).cab">v2sql_shared_language_reference_b4621_sql_130_en-us_1(83748a56-8810-751f-d453-00c5accc862d).cab</a>
        </div>
        <div class="package">
            <span class="name">v2SQL_Shared_Language_Reference_B4621_SQL_130_en-us_2</span>
            <span class="deployed">False</span>
            <a class="current-link" href="v2sql_shared_language_reference_b4621_sql_130_en-us_2(ccc38276-b744-93bd-9008-fe79b294ff41).cab">v2sql_shared_language_reference_b4621_sql_130_en-us_2(ccc38276-b744-93bd-9008-fe79b294ff41).cab</a>
        </div>
    </div>
</body>
</html>
      1. First, set the Help Viewer to open help from the local sources:
        1-viewer
      2. Then select the “Add and Remove Help Content” command:
        2-addremove
      3. This command opens the Help Viewer and asks for the content to add.
        Browse to the file you created in step 3.
        Click “Add” on all the items you wish to add to the library. In this case you will have only 1 item.
        When done, click the “Update” button.
        3-addcontent
      4. Unfortunately, during the installation phase of the library item, something crashes and the installation won’t proceed until you tell it to ignore or report the error.
        4-crash
      5. Despite the crash, everything works as expected and you will find the topic installed in your help library:
        5-installed

Here it is, nice and easy. Hope it works for you too.

ForumSurfer – a RSS reader for the SQL Server online community


Today I published the first release of ForumSurfer, a RSS reader designed explicitly to be a tool for the SQL Server online community.

Here is a screenshot:

ForumSurfer

ForumSurfer has some unique features that will help you help others online:

  • it is designed to help you keep an eye on multiple communities through their RSS feeds
  • it opens questions in the integrated web browser
  • it can update from the feeds much more often than online RSS readers do
  • it has built-in support for boilerplate answers
  • it supports high-DPI displays, letting you choose the appropriate zoom level for individual sites
  • it can import/export OPML files (you can start by importing the OPML file containing all the online SQL Server communities I’m keeping on the radar)

What are you waiting for? Download now the latest release of ForumSurfer and start being helpful!

Did you find any issues? Report them or ping me on Twitter!

SSMS is now High-DPI ready


One of the most popular posts on this bog describes how to enable bitmap scaling is SSMS on high DPI displays, which is a sign that more and more people are starting to use 4K displays and are unhappy with SSMS’s behaviour at high DPI. The solution described in that post is to enable bitmap scaling, which renders graphic objects correctly, at the price of some blurriness.

The good news is that starting with SSMS 16.3 high DPI displays are finally first class citizens and SSMS does its best to scale objects properly. By default, SSMS will keep using bitmap scaling: in order to enable DPI scaling you will have to use a manifest file.

  1. Merge this key to your registry:
Windows Registry Editor Version 5.00[HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\SideBySide]
"PreferExternalManifest"=dword:00000001
  1. Save this manifest file to “C:\Program Files (x86)\Microsoft SQL Server\130\Tools\Binn\ManagementStudio\Ssms.exe.manifest” using UTF-8 format:
<?xml version="1.0" encoding="UTF-8" standalone="yes"?>
<assembly xmlns="urn:schemas-microsoft-com:asm.v1" manifestVersion="1.0" xmlns:asmv3="urn:schemas-microsoft-com:asm.v3">
    <asmv3:application>
        <asmv3:windowsSettings xmlns="http://schemas.microsoft.com/SMI/2005/WindowsSettings">
            <dpiAware>True</dpiAware>
        </asmv3:windowsSettings>
    </asmv3:application>
    <dependency>
        <dependentAssembly>
            <assemblyIdentity type="win32" name="Microsoft.Windows.Common-Controls" version="6.0.0.0" processorArchitecture="X86" publicKeyToken="6595b64144ccf1df" language="*" />
        </dependentAssembly>
    </dependency>
    <dependency>
        <dependentAssembly>
            <assemblyIdentity type="win32" name="debuggerproxy.dll" processorArchitecture="X86" version="1.0.0.0"></assemblyIdentity>
        </dependentAssembly>
    </dependency>
</assembly>

This is a huge improvement over the bitmap scaling solution we had to use up to now: no more blurriness and proper fonts are used in SSMS.

For comparison, this is how bitmap scaling renders in SSMS 2014:

SSMS2014

And this is how DPI scaling renders is SSMS 16.3, with scaling set to 200%:

SSMS2016

As you can see, it’s not perfect yet (for instance, I had to change the grid font size to 9pt. in order to have readable fonts).

However, the GUI is much more readable now. For instance, look at the difference in object explorer: (click on the image to open fullsize and see the difference)

objexp

Now that your favourite tool is working in high DPI displays, nothing is holding you back from buying one of those fancy 4K laptops!

My Feedback on my PASS Abstracts Feedback


Brent Ozar recently published the feedback he got on his abstract submissions for PASS Summit 2016 and, as he often does, started a trend which some others followed. I think the feedback is interesting and useful for speakers that plan to improve their own submissions for the years to come, so I decided I will publish my feedback as well.

I did not get selected and, obviously, I would be happier if I got selected instead. This doesn’t mean I have problems with the selection process or the reviewers that implemented it. Instead I’m grateful for the enormous amount of work they did for the community, so a huge thank you goes to the committee.

Every year I see people publicly complain about the selection process or getting mad about being rejected. Folks, get over it: organizers have the right to choose whichever sessions they find more suitable for the Summit. It’s their responsibility to put together the best possible agenda and that doesn’t necessarily include your session.

That said, this is my feedback:

Responding to Extended Events in near real-time

Not Accepted: Higher rated session selected.

Category: General Session (75 minutes)

Track: Enterprise Database Administration & Deployment

Topic: Performance Monitoring / Tuning / Extended Events / Waits

Level: 300

Abstract: Extended Events provide deep insight into SQL Server’s behavior and allow us to gather information not available by other means. However, compared to other technologies such as SQL Trace and Event Notifications, a way to react to the events as soon as they happen seems to be lacking.
In this session we will see how the Extended Events streaming API can be used to process events in a near real-time fashion. We will demonstrate how this technology enables new possibilities to solve real world problems, such as capturing and notifying deadlocks or blocking sessions.

Prerequisites: Extended Events basics, C# basics, Powershell basics. The amount of coding required is in line with the average DBA skills.

Goal1:  Introduce Extended Events and compare them with other monitoring technologies available in SQL Server

Goal2:  Introduce the Extended Events streaming API and demonstrate how it can be used to process the events as soon as they occur, without shredding XML.

Goal3:  Demonstrate how the Extended Events streaming API can be used to solve real world problems, such as building a monitoring and alerting solution for deadlocks and blocked sessions.

Comments:

Needs more specifics in abstract.

A : 4 The abstract digs a little deeper on what’s being offered by XEs, and what needs to be done to efficiently capture events in near real-time without bogging down the system

T : 5 The topic matches with the goals – and many people hesitate capturing large amounts of .xel files fearing shredding the xml. This session offers a new approach to capturing the same using streaming APIs, with C#/PowerShell

S : 5 Prereqs are a little steep, but given the outcome – justified, and will interest people.

Level looks ok for the prereqs and goals. Topic is ok. Abstract is good overall. Only issue is the second sentence reads a little oddly.

Abstract: Well written abstract with strong supportive goals. Topic: Great topic!            Subjective: This sounds like a very interesting session. Taking xEvents to the next level. I would attend this session. I think it will be a large draw!

Feedback on comments:

“Needs more specifics in abstract”. What kind of specifics is needed in the abstract? A clue would be helpful here.

A/T/S: what do these letters stand for? I suppose they mean Abstract, Topic, Subjective. What do the numbers stand for? A mark maybe? Again, no explanation.

“The second sentence reads a little oddly”. I really don’t understand grammar or language comments. It’s not a conference on the English language and non-native speakers are already disadvantaged enough without being constantly reminded that their language skills can’t compare to Shakespeare’s. Speakers names are stripped away from the sessions, so the reviewers may not be aware that the session comes from a foreigner. If the topic is good and fits what the organizers are looking for, minor grammar/language mistakes can be fixed. BTW, one of the reviewers told me that when multiple sessions are on a tie, language is the tie breaker. Questionable, but understandable.

The feedback itself is not very useful for improving this submission for next year.

SQL Server Infernals: Worst Practices in Action

Not Accepted: Other sessions selected based on building a balanced program for track coverage, speaker coverage, topic coverage, and session rating.

Category: General Session (75 minutes)

Track: Enterprise Database Administration & Deployment

Topic: Internals: Storage Engine / Query Engine / Compression

Level: 100

Abstract: Let’s face it: Best Practices are too many to really know them all and choose which ones should be applied first. Does your telephone ring all the time? Do your users ask for that “quick report” that instead takes ages and keeps changing every time you think it’s done?
Have you ever thought that in dire times avoiding Worst Practices could be a good starting point and you can leave fine tuning for a better future? If the answer is “yes”, then this session is for you: we will discover together how not to torture a SQL Server instance and we will see how to avoid making choices that in the long run could turn out to be not as smart as they looked initially.

Prerequisites: Basic database design skills, basic development concepts, basic database administration skills.

Goal1: Demonstrate how bad Database Design decisions (irresponsible denormalization, EAV, bad data types, wrong or missing primary keys) can haunt a project through its whole lifetime.

Goal2: Illustrate how bad development practices (SQL Injection, RBAR, poor or no testing) can hurt performance, put security at risk and pose serious threats to the success of our projects.

Goal3: Enumerate and explain the worst installation and administration practices for SQL Server instances, offering the correct alternatives. Topics covered: HW choice, OS policies, security, ongoing administration, monitoring and tuning.

Comments:

Abstract: compelling

Topic: I like goals

Subjective rating: interesting, but level too low

Abstract: The outline and details of this abstract are well written

Topic: This is a great topic

Subjective: I may attend this session

The outline does not seem to clearly describe the contents of the presentation. The level of detail seems low – more detail might help attendees decide on value of attending. The title may not attract the appropriate attendees – it seems a little vague.

Abstract: Abstract is a little muddled. Goals are clearly laid out. Goals seem to contain the entire gamut of SQL Server. Perhaps a more focused area of SQL Server would help.

Topic: Title is cute.

Subjective: Could be a fun session.

Feedback on comments:

“Level too low”. Level is intentionally low: it’s meant as an introductory session. What to avoid is exactly that: an introductory topic for beginners. Have you ever noticed that basic introductory sessions pack the room? Should we take it as a clue that attendees want 100-level sessions? Apparently not.

“The outline does not seem to clearly describe the contents”. True, I agree. Next time I submit this session I will include in the abstract more details about the contents. It seems that including those details in the goals is not enough.

“Goals seem to contain the entire gamut of SQL Server”. True. I don’t see how this is a bad thing for an introductory session.

This feedback is much more useful than the other ones.

The shape of your Workload: Benchmarking and Baselining

Not Accepted: Higher rated session selected.

Category: General Session (75 minutes)

Track: Enterprise Database Administration & Deployment

Topic: Performance Monitoring / Tuning / Extended Events / Waits

Level: 300

Abstract: The key to optimizing SQL Server performance is to establish a performance baseline and thoroughly analyze the workload on the server. Collecting a baseline is not enough: it is important to analyze the workload in order to intervene effectively exactly where performance issues lie.
In this session we will describe the techniques and tools to analyze SQL Server performance and we will introduce benchmarking techniques that allow us to rate our tuning efforts. We will also introduce some tools included in SQL Server 2014, such as the Distributed Replay, and several third-party applications that come at little or no cost, but provide the highest benefit.

Prerequisites: Basic SQL Server performance tuning techniques (DMVs, Performance Counters), basic monitoring techniques (SQL Trace, Extended Events).

Goal1: Introduce SQL Server performance analysis tools (DMVs, Performance Counters, Data Collector) and demonstrate how to use them to collect a baseline.

Goal2: Introduce workload analysis techniques, using SQL Server and third party tools, including cache analysis queries, RML Utilities and ClearTrace.

Goal3: Demonstrate benchmarking techniques which will allow us to compare performance before and after applying tuning measures, using RML utilities, Distributed Replay and Qure Analyzer.

Comments:

Needs more specifics in abstract.

A : 5 The abstract clearly spells out the need for baseling, and benchmarking, to identify performance workload.

T : 5 The topic maps well with the session goals – and makes use of the Dist Replay Controller/Client to replay the prod workload on lower environments, and making use of RML utils and ClearTrace

S : 5 The prereqs are not steep, and the session offers a lot to replay prod workload on lower envs.

Topic is a good and relevant choice that appeals to a distinct attendee pool. Level appears good for the prereqs and goals.

Abstract is ok. Some word choices make the sentences difficult to follow (ie. ‘intervene effectively exactly’).

Abstract: Well written abstract with strong, supportive goals. Enough information is provided from which an attendee can make an informed decision on whether or not to attend this session.

Topic: Excellent topic. Likely a 200 level session, not 300.

Subjective: Great session which should draw in attendees. This is a skill every database professional needs.

Feedback on comments:

“Needs more specifics in abstract” and “enough information is provided” in the same feedback. Not very helpful.

“Some word choices make the sentences difficult to follow”. I’ve already said what I think about language comments.

Reading the comments, you would think it made the cut, but it didn’t. What can I say? Competition is tough: there are lots of great speakers with lots of great sessions.

“Likely a 200 level session, not 300”. I disagree: I’ve never seen anyone less than experienced fiddling with RML Utilities or distributed replay.

General feedback

The comments I received this time are less helpful than the ones I got last year on the same exact sessions. Yep: I submitted the same sessions last year and I got very useful comments that I used to improve my submissions this year. Unfortunately, it will be hard to improve next year.

The level discussion is completely subjective. I was under the impression that here in Europe we tend to rate sessions lower than Americans do, so a 200 session in Europe could easily be a 300 session in USA. Maybe my impression was wrong. However, it’s interesting to see how the session that I proposed with level 100 was deemed to be underrated and the one that I proposed with level 300 was deemed to be overrated. Levels are part of the session: the speaker chooses which level to go for and I would have a really hard time as a reviewer arguing against that decision without having seen the session.

Regarding the reason for rejection, I am not completely sure it can be helpful for improving next year’s submissions. For instance, my session on Extended Events got “Higher rated session selected” as the reason for rejection, but looking at the schedule there is no other session on Extended Events (which is quite surprising) and no other session on monitoring (which is even more surprising and maybe a bit disappointing). This means that the higher rated session does not have to be on the same topic, which makes the other reason for rejection (Other sessions selected based on building a balanced program for track coverage, speaker coverage, topic coverage, and session rating) difficult to decipher.

Lessons learned

  1. You’re selling the abstract, not the session
    The reviewers are evaluating your abstract, not your session. All your efforts should be pushed towards perfecting your abstract. Craft it as your masterpiece. Start well in advance, don’t wait for the last minute.
  2. Take as many shots as you can
    Looking at the selection process from the outside it’s really hard to tell how it works, so submitting multiple abstracts can increase your chances of scoring a session. Maybe that session that you don’t like is exactly what the committee is looking for. Again, you’re selling only the abstract and if you get selected you have several months to improve the session.
  3. There’s a review service offered by PASS. Use it.
    There is no guarantee that it is going to be the best feedback you will get, but it’s some feedback at least.
  4. You have friends in your #sqlfamily: ask for advice.
    If you don’t trust the feedback that you get from the PASS review service, trust your friends. If you’re submitting for PASS Summit, chances are that you already have spoken at SQLSaturdays or other community events (if not, maybe you should think twice before submitting: PASS Summit is not for inexperienced speakers). In this case, you got in touch with the community leaders in your chapter, who probably keep scoring sessions at Summit year after year: ask them to review your sessions. I am sure that they will have precious suggestions for you.
  5. If you’re not an English native speaker, ask a native speaker to proofread it
    Sure, your English is great. Sure, the reviewers have something to say about native speakers’ English as well. Sure, language should not be the focus of the reviewers. However, see lesson learned #1.
  6. Speaker/Abstract separation is a joke
    If you read Brent’s feedback, one thing emerges quite clearly: in many cases, the reviewers know exactly whose abstract they are reviewing. This might be because they already have seen the session somewhere else or because the abstract contains some “distinctive features” (sp_AskXXX anyone?). This means that some speakers have an advantage over the average Joe, but rightly so: those speakers are awesome and well known for being awesome. I’m not saying that the “Top Guns” can submit their grocery list: what I’m saying is that they are not selling only their abstracts. Now that Brent has published his abstracts, I wonder what would happen next year if somebody submitted one of his sessions… 🙂

Bottom line

Being selected for speaking at the PASS Summit is damn hard. I hope that sharing my feedback will help you improving your submission next year. I also hope that you will find my advice useful, if you dare accepting advice from somebody who never managed to score a session himself.

Upcoming Speaking Engagements


The next few months will be crazy for me. I will be travelling a lot around Europe, speaking about SQL Server topics.

Here is where you will find me in the upcoming weeks:

SQLNexus is a new conference in Copenhagen and will be the official launch event in Denmark for SQL Server 2016.
I will speak about “Responding to Extended Events in near Real-Time”.

SQLBits doesn’t need to be introduced. It’s the biggest SQL Server event in Europe and it will also be the official SQL Server 2016 launch event in UK.
Again, I will speak about “Responding to Extended Events in near Real-Time”.

NTK is a famous conference in Slovenia, which has been running for many years now. This year it will be held in Portorosz, near the Italian border.
It’s going to be fun: I will speak about “Benchmarking, Baselining and Workload Analysis”.

INSIDE-SQL is also a new event, run this year for the first time. It’s an event focused on in-depth concepts, delivered in 75 minutes sessions, with long breaks between sessions, so that attendees can go to the next session without rushing and can hang out with the speakers and ask questions.
I will deliver two sessions:
“Responding to Extended Events in near Real-Time”
“Advanced T-SQL Techniques”

Free SQL Server training from the 40th floor of the Tour Montparnasse in Paris.What else can I say?
I will be speaking about “New Security Features in SQL Server 2016”

One of the coolest SQLSats around!
This time I’ll be speaking about “SQL Server Infernals”, AKA “how to torture your SQL Server instances to death with worst practices”. It’s going to be fun!

I hope to see you at these super cool events!

An annoying Bug in the Restore Dialog


Today, thanks to a customer, I discovered  one of those annoying little things that can really drive you nuts.

Basically, they were trying to restore a backup using the SSMS Restore Database window and they kept getting “No backupset selected to be restored” whenever a backup file was selected.

You just had to select a file for restore and click OK…

chooseFile

… to be met with an error message in the Restore Database window:

Restore_Error_Initial

The weird thing about it is that the backup file restored perfectly fine from a T-SQL script:

T-SQL

So it had to be something wrong with SSMS, but what?

Looking closer at the restore script, one thing stands out. Look at the file name:

T-SQL_highlight

Yep, there’s a leading whitespace in the file name. Could that be the source of the problem?

Let’s try again with the GUI in a slightly different way. This time I will copy the folder path from the “Backup File Location” textbox…

chooseFile_CopyFolder

… and paste it directly in the “File name” textbox, right before the file name:

chooseFile_CopyFolder2

This time everything works as expected.

Bottom line:

  1. This is a bug in SSMS: go on and vote this Connect item to have it fixed in a future version.
  2. Don’t use the GUI to restore a database.
  3. Don’t use the GUI at all.

SSMS in High-DPI Displays: How to Stop the Madness


I spent the last few weeks travelling a lot compared to my usual routine and I got quickly fed up with bringing my mobile workstation with me. My Dell precision M4600 is a powerhouse, but it’s definitely too big and too heavy for travelling, so I decided it was time to buy a small laptop just for travelling and presenting at SQL Saturdays and events around Europe.

After lots of research, I pulled the trigger on a new XPS13. It’s a very nice, tiny and light machine, beefy enough to run my virtual machines and slim enough to fit in a small bag.

So, everything fine? Not quite. The XPS13 2015 sports a stunning QHD touch display, with almost no bezel: a small wonder. The only complaint with it is windows and its (in)ability to scale applications when running at High DPI.

Windows got better at scaling applications on HiDPI displays and Windows 10 is doing a remarkably good job at scaling applications that can actually scale. I am running at maximum resolution (3200 x 1800) with 200% scale factor and, for instance, Visual Studio 2015 renders perfectly:

VisualStudio

Other applications scale horribly. For instance, SSMS (SQL Server Management Studio) 2014 is a complete disaster:

SSMS_smart_scaling_200_percent

At a first glance, it looks ok, but look at those icons on the Object Explorer tree: aren’t they a little bit too small compared to the labels next to them?

I can live with small icons, but you just need to open some dialog windows to understand how bad things really are:

smart_scaling_200percent

As you can see, text gets scaled correctly, but the size of the window and some controls are completely wrong.

While some dialog windows are easily fixed by resizing them, some other are completely unusable. For instance, the restore database dialog, when locating a backup file, looks like this:

restore_scaling_issues

I’m not the first one to discover this kind of issues: Scott Hanselman posted his impressions quite a long time ago, but he offered no solution.

There’s also a Connect item that describes this issue, but… ok, you know what I’m about to say.

A new hope from an old technique

In Windows Vista, you had two possible ways of scaling applications: with the first one (the default) applications were instructed to scale their objects using the scaling factor imposed by the operating system. The results, depending on the quality of the application and the Windows version, could vary a lot. Some scaled correctly, some other look very similar to what we are seeing in SSMS, with some weird-looking GUIs. In Vista, this option was called “XP style DPI scaling”.

The second option, which you could activate by unchecking the “XP style” checkbox, involved drawing the graphical components of the GUI to an off-screen buffer and then drawing them back to the display, scaling the whole thing up to the screen resolution. This option is called “bitmap scaling” and the result is a perfectly laid out GUI:

SSMS_xp_scaling_200percent

In order to enable this option in Windows 10, you need to merge this key to your registry:

Windows Registry Editor Version 5.00

[HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\SideBySide]
"PreferExternalManifest"=dword:00000001

Then, the application has to be decorated with a manifest file that instructs Windows to disable DPI scaling and enable bitmap scaling, by declaring the application as DPI unaware. The manifest file has to be saved in the same folder as the executable (ssms.exe) and its name must be ssms.exe.manifest. In this case, for SSMS 2014, the file path is “C:\Program Files (x86)\Microsoft SQL Server\120\Tools\Binn\ManagementStudio\Ssms.exe.manifest”.

Paste this text inside the manifest file and save it in UTF8 encoding:

<?xml version="1.0" encoding="UTF-8" standalone="yes"?>

<assembly xmlns="urn:schemas-microsoft-com:asm.v1" manifestVersion="1.0" xmlns:asmv3="urn:schemas-microsoft-com:asm.v3">

<dependency>
  <dependentAssembly>
    <assemblyIdentity type="win32" name="Microsoft.Windows.Common-Controls" version="6.0.0.0" processorArchitecture="*" publicKeyToken="6595b64144ccf1df" language="*">
    </assemblyIdentity>
  </dependentAssembly>
</dependency>

<dependency>
  <dependentAssembly>
    <assemblyIdentity type="win32" name="Microsoft.VC90.CRT" version="9.0.21022.8" processorArchitecture="amd64" publicKeyToken="1fc8b3b9a1e18e3b">
    </assemblyIdentity>
  </dependentAssembly>
</dependency>

<trustInfo xmlns="urn:schemas-microsoft-com:asm.v3">
  <security>
    <requestedPrivileges>
      <requestedExecutionLevel level="asInvoker" uiAccess="false"/>
    </requestedPrivileges>
  </security>
</trustInfo>

<asmv3:application>
  <asmv3:windowsSettings xmlns="http://schemas.microsoft.com/SMI/2005/WindowsSettings">
    <ms_windowsSettings:dpiAware xmlns:ms_windowsSettings="http://schemas.microsoft.com/SMI/2005/WindowsSettings">false</ms_windowsSettings:dpiAware>
  </asmv3:windowsSettings>
</asmv3:application>

</assembly>

This “Vista style” bitmap scaling is very similar to what Apple is doing on his Retina displays, except that Apple uses a different font rendering algorithm that looks better when scaled up. If you use this technique in Windows, ClearType rendering is performed on the off-screen buffer before upscaling, so the final result might look a bit blurry.

The amount of blurriness you will see depends on the scale factor you set in the control panel or in the settings app in Windows 10. Needless to say that exact pixel scaling looks better, so prefer 200% over 225% or 250% scale factors, because there is no such thing as “half pixel”.

Seeing is believing:

Bitmap scaling at 200%

Bitmap scaling at 200%

Bitmap scaling at 225%

Bitmap scaling at 225%

Bitmap scaling at 250%

Bitmap scaling at 250%

That’s it: nice and easy. Enjoy your High DPI lifestyle, until Microsoft comes up with a better solution (or a better SSMS).
